Display Construction and Touch Performance
All available sizes support 3840 × 2160 4K UHD resolution, with screen brightness of 350–450 cd/m² and a standard 60Hz refresh rate.
An optional 120Hz configuration is available for projects requiring a higher display refresh rate.
The aluminum alloy frame is combined with 4 mm anti-glare tempered glass for touchscreen interaction.
Touch configurations include 20-point infrared or 10-point capacitive technology, with ±1 mm writing accuracy and response times of ≤8 ms.
Video Conferencing and Content Sharing
Optional wide-angle cameras include 8 MP, 13 MP, and 48 MP configurations, supporting different meeting video requirements.
A six-to-eight-microphone array provides an 8–12 m pickup range, with AI noise reduction and echo cancellation functions.
Wireless collaboration functions include Miracast, QR-code sharing, cloud collaboration, and synchronization across multiple devices.
HDMI, USB Type-A, Type-C, USB-B, RS232, and OPS connections support integration with computers and meeting peripherals.
Project Configuration and Factory Capabilities
Zhejiang Diankun Intelligent Technology Co., Ltd. provides OEM/ODM manufacturing for customized interactive display projects.
The Interactive Display Panel can be configured according to screen size, processor platform, touchscreen technology, camera equipment, and mounting requirements.
Production capabilities cover equipment design, enclosure processing, surface coating, complete assembly, and software development.
Buyers can specify Windows and Android system requirements together with the preferred x86 or Android computing configuration.
Equipment Selection and Purchasing Guidance
For collaborative writing projects, confirm the required touch technology, number of simultaneous users, and available installation space.
Video meeting applications should identify camera resolution, microphone requirements, speaker configuration, and connection interfaces.
Purchasing inquiries should include screen dimensions, mounting method, computing platform, and anticipated application software.
Technical requirements can be reviewed when selecting the appropriate Interactive Display Panel configuration for a meeting or presentation environment.
Product Specifications
|
Parameter |
Specification |
|
Screen Sizes |
55 / 65 / 75 / 86 / 98 inches |
|
Display Resolution |
4K UHD 3840 × 2160 |
|
Touch Technology |
20-point infrared / 10-point capacitive; ±1 mm |
|
Computing Platform |
x86 i5/i7 or Android; optional OPS-C |
|
Installation |
Wall-mounted / Mobile stand |
